Easy Laser XT770
The Easy Laser XT770 is the top of the range of the Generation XT shaft alignment systems. This Easy Laser XT 770 won the Plant Services Magazine Product of the year and its XT11 display has won numerous design awards.
Easy Laser XT770 Features
- 360° Live – Adjust in vertical and horizontal directions at the same time with lasers in any position with the Easy Laser XT770.
- Dual Beam, 2 axis dot laser system for longer spans and complex measurements on the Easy Laser XT770
- Programs for Machine trains (unlimited) and Cardan/Offset Shafts
- Measure Straightness, Flatness, Squareness and Parallelity
- Multi-Point, Continuous & Uncoupled Sweep measurement methods
- EasyTrend function for live thermal expansion monitoring with the Easy Laser XT770
- Digital Belt Alignment Tool Integration
- Vibrometer Tool Integration
- Built-in Thermal and Digital Camera
- The free XT Alignment app runs on Android and iOS devices with all functions included.
- Measurement Range up to 20m for the Easy Laser XT770
- Shaft Diameters up to 250mm and with extension chains up to 450mm.
In the box
Specifications
Datasheets
In the box
All Easy-Laser® XT770 Shaft systems include:
- 1 Measuring unit XT70-M
- 1 Measuring unit XT70-S
- 2 Shaft brackets with chains and rods 120 mm
- 4 Rods 75 mm
- 4 Rods 120 mm
- 2 Magnet bases
- 2 Offset brackets
- 2 Extension chain 900 mm
- 1 Measuring tape 3 m
- 1 Hexagon wrench set
- 1 Charger (100–240 V AC)
- 1 DC split cable for charging
- 1 DC to USB adapter, for charging
- 1 Quick reference manual
- 1 Cleaning cloth for optics
- 1 USB memory with manuals
- 1 Documentation folder
- 1 Carrying case Large (or Large Geo)
Part No. 12-1095 and 12-1127, also include:
- 1 Display unit XT11
- 1 Shoulder strap for display unit
Part No. 12-1127 and 12-1128 also include:
- 1 Laser transmitter D22
- 1 Magnet base with turnable head (replaces one of the regular magnet bases)
- 4 Rods 120 mm
Customize your XT11 (Note that these options cannot be retrofitted):
- IR Camera added to XT11
- Digital camera (and LED light) removed from XT11
Specifications
| XT770 – System Specifications | |
| Measuring units XT70-M / XT70-S | |
| Type of detector | 2 axis TruePSD 20×20 mm |
| Communication | BT wireless technology |
| Battery type | Heavy duty Li Ion chargeable |
| Operating time | Up to 24 h continuously |
| Resolution | 0.001 mm |
| Measuring errors | <1% |
| Measurement range | Up to 20 m |
| Type of laser | Diode laser |
| Laser wavelength | 635–670 nm |
| Laser class | Safety class 2 |
| Laser output | <1 mW |
| Electronic inclinometer | 0.1° resolution |
| Environmental protection | IP class 66 and 67 |
| Operating temperature | -10–50 °C |
| Storage temperature | -20–50 °C |
| Relative humidity | 10–95% |
| OLED display | 128×64 pixels |
| Housing material | Anodized aluminium + PC/ABS + TPE |
| Dimensions | WxHxD: 76×76.7×45.9 mm |
| Weight | 272 g |
| Display unit XT11 | |
| Type of display/size | SVGA 8″ colour screen, backlit LED, multitouch |
| Battery type | Heavy duty LiIon chargeable |
| Operating time | Up to16 h continuously |
| Connections | USB A, USB B, Charger, AV |
| Communication | Wireless technology, Wi-Fi |
| Camera, with diode lamp | 13 Mp |
| IR camera (optional) | FLIR LEPTON® (0–450 °C) |
| Languages | en / de / sv / es / pt / ru / ja / ko / zh / it / fr / pl |
| Help functions | Built-in manual |
| Environmental protection | IP class 66 and 67 |
| Operating temperature | -10–50 °C |
| Storage temperature | -20–50 °C |
| Relative humidity | 10–95% |
| OLED display | 96×96 pixels |
| Housing material | PC/ABS + TPE |
| Dimensions | WxHxD: 274x190x44 mm |
| Weight | 1450 g |
| Cable | |
| Charging cable (splitter cable) | Length 1 m |
| Brackets etc. | |
| Shaft brackets | Type: V-bracket for chain, width 18 mm |
| Shaft diameters: 20–150 mm | |
| With extension chain, diameters up to 450 mm | |
| Material: anodised aluminium | |
| Rods | Length: 120 mm, 75 mm, (extendable) |
| Material: Stainless steel |
